Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
System Status File 483
STI Set Point
This address is duplicated at STI:0/SPM. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 268 for more information.
STI File Number
This address is duplicated at STI:0/PFN. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 268 for more information.
Channel 0 Communications
Incoming Command Pending
This address is duplicated in the Communications Status File at CS0:0.4/0.
SeeGeneral Channel Status Block on page 58 for more information.
Message Reply Pending
This address is duplicated in the Communications Status File at CS0:0.4/1.
SeeGeneral Channel Status Block on page 58 for more information.
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:30 word 0 to 65535 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:31 word 0 to 65535 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:33/0 binary 0 or 1 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:33/1 binary 0 or 1 status read only
