501 Publication 1763-RM001C-EN-P - October 2009

Appendix

Protocol Configuration

Use the information in this appendix for configuring communication

protocols. The following protocols are supported from any RS-232

communication channel:

• DH-485

• DF1 Full-Duplex

• DF1 Half-Duplex

• DF1 Radio Modem

• Modbus RTU

• ASCII

This appendix is organized into the following sections:

• DH-485 Communication Protocol on page 502

• DF1 Full-Duplex Protocol on page 505

• DF1 Half-Duplex Protocol on page 506

• DF1 Radio Modem Protocol on page 517

• Modbus RTU Protocol on page 524

• ASCII Driver on page 534

• Ethernet Driver on page 536

See your controller’s User Manual for information about required network

devices and accessories.
