Publication 1763-RM001C-EN-P - October 2009
Function Files 75
127
128
Low word RMON Rx Packets
(RMON_R_PACKETS)
High word
129
130
Low word RMON Tx Packets
(RMON_T_PACKETS)
High word
131
132
Low word Frames Transmitted with Excessive Collisions
(IEEE_T_EXCOL)
High word
133
134
Low word Frames Received with CRC Error
(IEEE_R_CRC)
High word
135
136
Low word Frames Received with Alignment Error
(IEEE_R_ALIGN)
High word
137
138
Low word Count of frames not counted correctly
(RMON_T_DROP)
High word
139
140
Low word Receive FIFO Overflow Count
(IEEE_R_MACERR)
High word
141
142
Low word Frames transmitted with Tx FIFO Under-run
(IEEE_T_MACERR)
High word
143
144
Low word Frames Transmitted with Single Collision
(IEEE_T_1COL)
High word
145
146
Low word Frames Transmitted with Multiple Collisions
(IEEE_T_MCOL)
High word
147
148
Low word Frames Transmitted with Deferral Delay
(IEEE_T_DEF)
High word
149
150
Low word Frames Transmitted with Late Collisions
(IEEE_T_LCOL)
High word
151
152
Low word Frames Transmitted with Carrier Sense Errors
(IEEE_T_CSERR)
High word
153
154
Low word RMON Tx Collision Count
(RMON_T_COL)
High word
Ethernet Diagnostic Counters Block
Word Bit Description
