Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
78 Function Files
The last Port tab will show the current states of Ethernet communications
port according to word 5 of Ethernet Communications Status File.
Ethernet Diagnostic Counters Block (continued)
Word Bit Description
169
170
Low word Total Message Connections
High word
171
172
Low word Total Incoming Messages
High word
173
174
Low word Total Outgoing Messages
High word
175
176
Low word Maximum Connections Allowed
High word
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
