Allen-Bradley PowerFlex 400 - Approximate Dimensions

28
Specifications
For further information visit: www.abpowerflex.com or www.ab.com/support/abdrives
Approximate Dimensions
Ratings are in kW and (HP).
Panel Mount Drive
Frame 240V AC – 3-Phase 480V AC – 3-Phase
C 2.2 (3.0)
3.7 (5.0)
5.5 (7.5)
7.5 (10)
2.2 (3.0)
4.0 (5.0)
5.5 (7.5)
7.5 (10)
11 (15)
15 (20)
D11 (15)
15 (20)
18.5 (25)
22 (30)
18.5 (25.0)
22.0 (30.0)
30 (40)
E30 (40)
37 (50)
37.0 (50.0)
45.0 (60.0)
55 (75)
75 (100)
F – 90 (125) 110 (150)
G – 132 (200) 160 (250)
H – 200 (300) 250 (350)
260
(10.2)
320
(12.6)
246
(9.7)
130.0 (5.1)
116.0 (4.57)
111.2
(4.38)
152.2
(5.99)
∅ 22.2
(0.87)
∅ 28.5
(1.12)
107.0 (4.21)
66.0 (2.60)
24.0 (0.94)
180.0 (7.1)
226.0 (8.90)250.0 (9.84)
206.1 (8.11)
383.4
(15.09)
436.2
(17.17)
71.6 (2.82)
132.0 (5.20)
175.5 (6.91)
192.0 (7.56)
156.3
(6.15)
132.7
(5.22)
167.4
(6.59)
∅ 22.2
(0.87)
∅ 28.5
(1.12)
∅ 9.0
(0.35)
Frame C
(Shown with IP30, NEMA/UL Type 1 conversion kit.)
Frame D
