76 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019
Chapter 4 Configure Integrated Motion Control Using Kinetix 5700 Drives
The Safety Network Number (SNN) field populates automatically
when the Connection mode includes an integrated Motion and Safety
or Safety-only connection. For a detailed explanation of the safety
network number, refer to the appropriate GuardLogix controller
publication as defined in Additional Resources on page 9
.
5. To close the Module Definition dialog box, click OK.
6. Click Apply.
Configure the Power and Safety Options
1. Click the Power category.
IMPORTANT The Logix Designer application enforces shared-bus configuration rules for
Kinetix 5700 drives.
