Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 75
Programming and Parameters Chapter 1
Ramped Speed 22 Metering 23
Rated Amps 28 Drive Data 23
Rated kW 26 Drive Data 23
Rated Volts 27 Drive Data 23
Reference Mask 280 Masks and
Owners
61
Reference Owner 292 Masks and
Owners
62
Regen Power Lim 153 Load Limits 42
Reset Meters 200 Drive Memory 50
Reset To Defalts 197 Drive Memory 50
Rev Speed Limit 454 Spd Mode and
Limits
32
Run Boost 70 Volts per Hertz 29
S Curve % 146 Ramp Rates 41
Save HIM Ref 192 HIM Ref Config 49
Save MOP Ref 194 MOP Config 50
Save To User Set 199 Drive Memory 50
Scale1 In Hi 476 Scaled Blocks 59
Scale1 In Lo 477 Scaled Blocks 59
Scale1 In Value 478 Scaled Blocks 59
Scale2 In Hi 482 Scaled Blocks 59
Scale2 In Lo 483 Scaled Blocks 59
Scale2 In Value 484 Scaled Blocks 59
Shear Pin Time 189 Load Limits 42
Skip Freq Band 87 Spd Mode and
Limits
32
Skip Frequency X 84…86 Spd Mode and
Limits
32
Sleep Level 182 Restart Modes 48
Sleep Time 183 Restart Modes 48
Sleep Wake Mode 178 Restart Modes 47
Sleep Wake Ref 179 Restart Modes 48
Slip Comp Gain 122 Slip Comp 36
Slip RPM @ FLA 121 Slip Comp 36
Slip RPM Meter 123 Slip Comp 36
Spd Err Filt BW 448 Speed
Regulator
39
Speed Desired BW 449 Speed
Regulator
40
Speed Feedback 25 Metering 23
Speed Loop Meter 451 Speed
Regulator
40
Speed Mode 80 Spd Mode and
Limits
31
Speed Ref X Hi 91, 94 Speed
Reference
33
Speed Ref X Lo 92, 95 Speed
Reference
33
Speed Ref X Sel 90, 93 Speed
Reference
33
Speed Reference 23 Metering 23
Speed Ref Source 213 Diagnostics 54
Speed/Torque Mod 88 Spd Mode and
Limits
32
Start At PowerUp 168 Restart Modes 45
Start Inhibits 214 Diagnostics 54
Start Mask 277 Masks and
Owners
61
Start Owner 289 Masks and
Owners
62
Start/Acc Boost 69 Volts per Hertz 29
Status X @ Fault 227, 228 Diagnostics 56
Parameter Name Number Group Page
Status 3 @ Fault 223 Diagnostics 56
Stop/Brk Mode X 155, 156 Stop/Brake
Modes
42
Stop Owner 288 Masks and
Owners
62
SV Boost Filter 59 Torq Attributes 26
Sync Time 622 Fiber Functions 72
TB Man Ref Hi 97 Speed
Reference
34
TB Man Ref Lo 98 Speed
Reference
34
TB Man Ref Sel 96 Speed
Reference
34
Testpoint X Data 235, 237 Diagnostics 58
Testpoint X Sel 234, 236 Diagnostics 58
Torq Current Ref 441 Torq Attributes 29
Torque Current 4 Metering 22
Torque Estimate 15 Metering 23
Torque Perf Mode 53 Torq Attributes 25
Torque Ref A Hi 428 Torq Attributes 28
Torque Ref A Lo 429 Torq Attributes 28
Torque Ref A Sel 427 Torq Attributes 28
Torque Setpoint1 435 Torq Attributes 28
Total Inertia 450 Speed
Regulator
40
Traverse Dec 624 Fiber Functions 72
Traverse Inc 623 Fiber Functions 72
Trim % Setpoint 116 Speed Trim 35
Trim Hi 119 Speed Trim 36
Trim In Select 117 Speed Trim 35
Trim Lo 120 Speed Trim 36
Trim Out Select 118 Speed Trim 36
Voltage Class 202 Drive Memory 51
Wake Level 180 Restart Modes 48
Wake Time 181 Restart Modes 48
Write Mask Act 597 Security 64
Write Mask Cfg 596 Security 64
Parameter Name Number Group Page

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
