166 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 8 Configuration Examples for a Kinetix Drive

7. From the Load Feedback Device pull-down menu, choose Aux

Feedback Port.

8. To apply your changes and return to the Load Feedback dialog box, click

OK.

Figure 31 - Example 2: Kinetix 6500 Module Properties, Associated Axis Tab

9. Choose the Feedback Type and Units.

Figure 32 - Example 2: Position Loop with Dual Feedback, Load Feedback Dialog Box

Default values for Resolution and Interpolation

are automatically provided. You must enter the

actual resolution of load-side feedback device.
