Appendix B
Out of Box Configuration for PowerFlex Drives
This appendix describes how to program a velocity profile and jerk rate.
Program a Velocity Profile
and Jerk Rate
You can use either of these motion profiles for various instructions:
• Trapezoidal profile for linear acceleration and deceleration
• S-curve profiles for controlled jerk
Definition of Jerk
The Jerk is the rate of change of acceleration or deceleration.
The jerk parameters apply only to S-curve profile moves that use these
instructions:
For example, if acceleration changes from 0 to 40 mm/s
2
in 0.2 seconds, the
jerk is:
(40 mm/s
2
- 0 mm/s
2
) / 0.2 s = 200 mm/s
3
Topic Page
Program a Velocity Profile and Jerk Rate 305
Enter Basic Logic 316
Choose a Motion Instruction 318
Troubleshoot Axis Motion 321
Programming with the MDSC Function 329
PowerFlex Out-of-Box Configuration 332
Setting the ACO/AVO Attributefor PF527 Drives Only 336
•MAJ •MCS
•MAM •MCCD
•MAS •MCCM
•MCD •MCLM

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
