Allweiler AE1F Series - Section Drawings for Series AE1+1 H, AE2+2 H, AE2+2 V, AE4+4 V; ID Construction Type

Spare parts
760.0002 GB - 150 500 BA-2011.11
Series AE1F, AE1L, AE.E, AE.N, AE.H, AE.V, AED1E,
AED2N ID, ZD construction types
39
11 Spare parts
The following sectional drawings show all
referenced pumps with various versions of the
shaft seals and bearings. Index of parts also
included. The parts labeled in the index of
parts can be used as spare/reserve parts.
Caution!
For safety reasons, stock and use
only original spare parts provided
by Allweiler. Refer to the
information provided under Section
2.7 ( page 5)!
When ordering spare or reserve parts, always
provide the following information:
• Pump number
• Pump model
• Part number
• Description and quantity of the part
• or ID number and quantity
Notice!
The pump number and pump model
are stamped onto the nameplate.
Refer to the attached list of spare
parts for the ID number and
quantity.
