Spare parts
Index of spare parts and recommended
spare/reserve parts
40
Series AE1F, AE1L, AE.E, AE.N, AE.H, AE.V, AED1E,
AED2N ID, ZD construction types
BA-2011.11 760.0002 GB - 150 500
11.1 Index of spare parts and recommended spare/reserve parts
Legend:
R = large repair kit
r = small repair kit
Part No. Description Repair kit Quantity Remarks
101 Key 1
102 Spacer sleeve 1
103 Groove ball bearing R 1
104 Angular-contact ball bearing R 1

107 Bearing grease R

110 Bearing bracket 1
112 Shaft seal ring R 1
113 Spacer ring 1
114 Thrower 1
115 O-ring R 1
116 Bearing nut R 1
118 Drive shaft R 1
119 Grease nipple 1
127 Circlip 1
129 Spacer ring 4
131 Bearing cover 1
132 Gasket R 1
139 Hexagon head screw 4
201 Stud bolt 2
202 Self-locking nut 2
203 Stuffing box gland half 2
204 Stuffing box casing 1
206 Shaft sleeve R 1

2 pieces with:
• AE1F 3003 / 5503
• AE1L 2701 / 5001
• AE1E 1450 / 2700 / 5000 / 9500
• AED1E 2300 / 4250 / 7800 / 15500
• AE1N 750 / 1450 / 2700 / 5000
• AE2N 750 / 1450
• AED2N 1200 / 2300 / 4250 / 7800
• AE.H 380 / 750 / 1450 / 2700
• AE.V 200 / 380 / 750 / 1450

see table in Section 9.1.3 page 22
