Spare parts
Index of spare parts and recommended
spare/reserve parts
760.0002 GB - 150 500
BA-2011.11
Series AE1F, AE1L, AE.E, AE.N, AE.H, AE.V, AED1E,
AED2N ID, ZD construction types
41
Part No. Description Repair kit Quantity Remarks
207 Gland packing R, r
208 Flushing ring 1
209 Seal chamber ring 1
212 Screw plug 1
213 Joint tape 1
214 Mechanical seal casing 1
215 Mechanical seal lid 1
218 O-ring R 1
219 Mechanical seal R 1
220 Locking pin 1
232 Shaft seal ring R 1
234 Throttle ring R 1
235 O-ring R 1
236 Locking pin R 2
245 Hexagon head screw 3
251 Sealing material 1
301 Joint pin R, r 2
302 Joint bush R, r 2
303 Bush for joint pin R, r 4
304 Joint sleeve R, r 2
305 Joint oil R, r
306 Joint clamp R, r 4
307 Joint shaft R, r 1
308 Joint collar R, r 2
401 Rotor R, r 1
402 Stator R, r 1
403 Pressure-side stator seal R, r 1
404 Suction-side stator seal R, r 1
501 Seal for suction casing R, r 1
502 Screw plug 1
503 Joint tape 1
504 Pressure housing 1
505 Suction casing 1
506 Suction casing lid 2
see table in Section 9.1.3 page 22
2 pieces on version G.D
not present on:
• AE1F 103
• AE1L 51 / AE1L 101, AE1E 50
• AE2E 50, AE1N 25 / AE2N 25
• AED1E 75, AED2N 38, AE4H 12
