Alto-Shaam COMBITHERM CTC Series - Boiler System: 6-10, 10-10, 7-20, 208 V, 1 PH, 3 PH, Simple & Touch

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 103
77623 used on units aer 7-31-15
Wiring Diagram 77623

   

  



 

 

77623
6.10-10.10-7.14 1 & 3 PH 208-240V BOILER
AFT
07/27/15 8 OF 42
208 - 240V, 3PH
7-20, 10-10 (10.7KW X2)
208 - 240V, 1PH
6-10 (10.7KW )
208 - 240V, 3PH
6-10 (10.7KW)
5015344-W
# WI-STOCK T-CONN. FROM
TERM
LOC TO
TERM
LOC L-CONN.
45 WI-3816 CR-34781 TB1 2 K1 1 CR-34775
46 WI-3816 CR-34781 TB6 2 K1 3 CR-34775
47
WI-3816 CR-34781
TB11 2 K1
5 CR-34775
48 WI-3816 CR-34781
TB1 2 K2 1
CR-34775
50 WI-3816 CR-34781 TB6 2 K2 3 CR-34775
52 WI-3816 CR-34781 TB11 2 K2 5 CR-34775
54 WI-33777 CR-34774 N9
11 K1 21
CR-38389
55 WI-33777 CR-38389
K1 22 N7 12
CR-33509
57 WI-33478 CR-38389 K2 A1 K1 A1 CR-38389
58 WI-33777 CR-38389 K2 A2 K1 A2 CR-38389
62 WI-33777 CR-33509 N9
11 TB27
18 CR-34783
341 WI-33776 CR-33509 SG2 GND SG3 GND CR-34774
342 WI-33776 CR-34783 TB51 3 SG3 GND CR-33509
66 WI-33777 CR-33509 N9 12 K2 A2 CR-38389
208 - 240V, 1PH
7-20, 10-10 (10.7KW X2)
5015377-W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
45 WI-3816 CR-34781
TB1 2 K1 2
CR-34775
46 WI-3816 CR-34781 TB6
2 K1 4
CR-34775
48 WI-3816 CR-34781 TB1 2 K2 2 CR-34775
50 WI-3816 CR-34781 TB6 2 K2 4 CR-34775
54 WI-33777 CR-34774 N9
11 K1 21
CR-38389
55 WI-33777 CR-38389 K1 22 N7 12 CR-33509
63 WI-33777 CR-33509 N9 11 TB27 18 CR-34783
341 WI-33776 CR-33509 SG2 GND SG3 GND CR-34774
342 WI-33776 CR-34783 TB51 3 SG3 GDN CR-33509
66 WI-33777 CR-33509 N9 12 K1 A2 CR-38389
5015343-W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
45 WI-3816 CR-34781
TB1 2 K1 2
CR-34775
46 WI-3816 CR-34781 TB6 2 K1 4 CR-34775
47 WI-3816 CR-34781 TB11 2 K1 6 CR-34775
54 WI-33777 CR-34774 N9 11 K1 21 CR-38389
55 WI-33777 CR-38389
K1 22 N7 12
CR-33509
63 WI-33777 CR-33509 N9 11 TB27 18 CR-38389
342 WI-33776 CR-33509 SG3 GND TB51 3 CR-34783
66 WI-33777 CR-33509 N9
12 K1 A2
CR-38389
5015346-W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
45 WI-3816 CR-34781 TB1 2 K1 2 CR-34775
46 WI-3816 CR-34781 TB6 2 K1 4 CR-34775
54 WI-33777 CR-34774 N9
11 K1 21
CR-38389
55 WI-33777 CR-38389
K1 22 N7 12
CR-33509
63 WI-33777 CR-38389 N9 11 TB27 18 CR-34783
342 WI-33776 CR-33509 SG3 GND TB51 3 CR-34783
66 WI-33777 CR-33509 N9
12 K1 A2
CR-38389
Boiler System: 6-10, 10-10, 7-20, 208V, 1PH, 3PH, Simple & Touch
