120 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
77623 used on units aer 7-31-15
 


 



 
   
 

77623
VENT-LESS HOOD
AFT
07/27/15 25 OF 42
5017012-3W
#
WI-STOC
K T-CONN. FROM
TERM
LOC TO TERM LOC L-CONN.
464 WI-33478 CR-34783 TB33 18 PSSW
COMMON CR-34774
465 WI-33478 CR-33509 FLTSW1
1
PSSW
COMMON
CR-33509
466 WI-33777 CR-34783 OB-X04 1 PSSW
NORMAL OPEN CR-33509
467 WI-33478 CR-33509 FLTSW1 2 FLTSW2 1 CR-33509
468 WI-33777 CR-34783 OB-X04
2
FLTSW2
2
CR-33509
469 WI-33777 CR-34783 TB45 6 VH-MOTOR
BLK
CR-34639
470 WI-33478 CR-34774 VH-MOTOR BLU F12 1 CR-34783
471 WI-33478 CR-34783 OB-X05 2 F12 2 CR-34783
Wiring Diagram 77623
Ventless Hood
