MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 155
77529 used on units previous to 8-1-15
Wiring Diagram 77529
77529
6.10 TO 10.18 380-415V 3Ph 50HZ CONVECTION
AFT
380-415V, 3PH
10-20 (33.0KW)
380 - 415V, 3PH
6-10,7-20,10-10 (10.5KW,21.9KW, 18.9KW)
5015370-5W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
60 WI-3816 CR-34781
TB1 1 K77 2
CR-34781
60 WI-3816 CR-34781 TB1 1 K77 2 CR-34781
61 WI-3816 CR-34781 TB6 1 K77 4 CR-34781
61 WI-3816 CR-34781 TB6 1 K77 4 CR-34781
62 WI-3816 CR-34781
TB11 1 K77
6 CR-34781
62 WI-3816 CR-34781 TB11 1 K77 6 CR-34781
63 WI-3816 CR-34775 F40 2 K77 1 CR-34781
63 WI-3816 CR-34775 F40 2 K77 1 CR-34781
64 WI-3816 CR-34775
F41 2 K77
3 CR-34781
64 WI-3816 CR-34775
F41 2 K77
3 CR-34781
65 WI-3816 CR-34775 F42 2 K77 5 CR-34781
65 WI-3816 CR-34775 F42 2 K77 5 CR-34781
66 WI-3816 CR-34775 F40 1 K41 1 CR-34775
67 WI-3816 CR-34781
K44 1
F40
1
CR-34775
68 WI-3816 CR-34775 F41 1 K41 3 CR-34781
69 WI-3816 CR-34781 K44 3 F41 1 CR-34775
70 WI-3816 CR-34775 F42 1 K41 5 CR-34781
72
WI-3816 CR-34781
K41 2
CH1
1-1
CR-3071
73 WI-3816 CR-34781
K41 4
CH1
2-1
CR-3071
74 WI-3816 CR-34781 K41 6 CH1 3-1 CR-3071
75 WI-3816 CR-3071 CH1 2-2 CH1 1-2 CR-3071
76 WI-3816 CR-3071 CH1
2-2
CH1 3-2 CR-3071
78 WI-3816 CR-34781
K41
6 CH1
4-1
CR-3071
79 WI-3816 CR-34781 TB17 1 CH1 4-2 CR-3071
80 WI-33478 CR-34783 TB35 10 K77 A1 CR-3593
81 WI-33777 CR-3593 K77 A2 N7 11 CR-33509
83 WI-33777 CR-3593
K41 A2 K44 A2
CR-3593
84 WI-3816 CR-34781
K44 2
CH1 5-1 CR-3071
85 WI-3816 CR-34781 K44 4 CH1 6-1 CR-3071
87 WI-3816 CR-3071 CH1 5-2 CH1 6-2 CR-3071
89 WI-3816 CR-3071 CH1 5-2 TB16
1
CR-34781
103 WI-33777 CR-3593
K44 A2 N7 11
CR-34774
104 WI-33777 CR-33509 N7 12 TB27 18 CR-3593
105 WI-33777 CR-33509 N7 31 CB-X10 8 CR-34783
106 WI-33777 CR-33509 N7 32 CB-X10 7 CR-34783
5015371-5W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
60 WI-3816 CR-34781 TB1 1 K77 2 CR-34781
60 WI-3816 CR-34781 TB1 1 K77 2 CR-34781
61 WI-3816 CR-34781 TB6 1 K77 4 CR-34781
61 WI-3816 CR-34781 TB6
1 K77 4
CR-34781
62 WI-3816 CR-34781 TB11 1 K77 6 CR-34781
62 WI-3816 CR-34781 TB11 1 K77 6 CR-34781
63 WI-3816 CR-34775 F40 1 K77 1 CR-34781
63 WI-3816 CR-34775 F40
1 K77 1
CR-34781
64 WI-3816 CR-34775
F41 1 K77
3 CR-34781
64 WI-3816 CR-34775 F41 1 K77 3 CR-34781
65 WI-3816 CR-34775 F42 1 K77 5 CR-34781
65 WI-3816 CR-34775 F42 1 K77 5 CR-34781
66 WI-3816 CR-34775 F40
2 K41 1
CR-34781
68 WI-3816 CR-34775 F41 2 K41 3 CR-34781
69 WI-3816 CR-34775 F42 2 K44 5 CR-34781
70 WI-3816 CR-34775 F42 2 K41 5 CR-34781
71
WI-3816 CR-34781
K41 2
CH1
1-1
CR-33008
72
WI-3816 CR-34781
K41 4
CH1
2-1
CR-33008
74 WI-3816 CR-33008 CH1 1-2 CH1 2-2 CR-33008
77 WI-3816 CR-33008 CH1 2-2 TB16 1 CR-34781
80 WI-33478 CR-34783 TB35 10 K77 A1 CR-3593
81 WI-33777 CR-3593
K77 A2 N7 11
CR-33509
83 WI-33777 CR-3593 K41 A2 K44 A2 CR-3593
86 WI-3816 CR-34781 K44 6 CH1 3-1 CR-33008
88 WI-3816 CR-33008 CH1 3-2 TB16 1 CR-34781
103 WI-33777 CR-3593
K44 A2 N7 11
CR-34774
104 WI-33777 CR-33509
N7 12 TB17
18 CR-34783
105 WI-33777 CR-33509 N7 31 CB-X10 8 CR-34783
106 WI-33777 CR-33509 N7 32 CB-X10 7 CR-34783
5017439-1W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
50 WI-33478 CR-34783 CB-X02 7 K45 A1 CR-3593
67 WI-3816 CR-34781 K45 1 F40 2 CR-34775
91 WI-33777 CR-3593
K44 A2
K45
A2
CR-3593
96 WI-3816 CR-34781 K45
2
CH1
4-1
CR-33008
99 WI-3816 CR-33008 CH1 4-2 TB17 1 CR-34781
5017440-1W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
50 WI-33478 CR-34783 CB-X02 7 K45 A1 CR-3593
71 WI-3816 CR-34781 K45 5 F42 1 CR-34775
91 WI-33777 CR-3593
K44 A2
K45
A2
CR-3593
96 WI-3816 CR-34781 K45 6 CH1
7-1
CR-3071
99 WI-3816 CR-3071 CH1 7-2 TB17 1 CR-34781
Convection System: 6-10, 10-10, 7-20, 10-20, 380V, 3PH, Touch
