Alto-Shaam COMBITHERM CTC Series - Convection System: 20-20, 208 V, 3 PH, Touch

154 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
77529 used on units previous to 8-1-15
Wiring Diagram 77529
208 - 240V, 3PH
20-20 (33.0KW x2)

    





 

 

77529
20.20 208V 3PH CONVECTION
AFT
04/12/12 15 OF 42
(5.6KW)
0
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L -CONN.
60 WI-3816 CR-34781 TB1 1 F40 2 CR-34781
60 WI-3816 CR-34781 TB1 1 F40 2 CR-34781
61 WI-3816 CR-34781 TB6 1 F41 2 CR-34781
61 WI-3816 CR-34781 TB6
1 F41 2
CR-34781
62 WI-3816 CR-34781 TB11 1 F42 2 CR-34781
62 WI-3816 CR-34781 TB11 1 F42 2 CR-34781
63 WI-3816 CR-34781 K41 2 F40 1 CR-34781
63 WI-3816 CR-34781
K41 2
F40
1
CR-34781
64 WI-3816 CR-34781 K41 4 F41
1
CR-34781
64 WI-3816 CR-34781 K41 4 F41 1 CR-34781
65 WI-3816 CR-34781 K41 6 F42 1 CR-34781
65 WI-3816 CR-34781 K41 6 F42 1 CR-34781
66 WI-3816 CR-34781
K41 1
CH1 3-2 CR-3071
67 WI-3816 CR-34781 K41 1 CH1 1-2 CR-3071
68 WI-3816 CR-34781 K41 3 CH1 1-1 CR-3071
69 WI-3816 CR-34781 K41 3 CH1 2-1 CR-3071
70 WI-3816 CR-34781
K41
5
CH1 2-2
CR-3071
71 WI-3816 CR-34781 K41 5 CH1 3-1 CR-3071
72 WI-3816 CR-34781 K42 1 CH2 3-2 CR-3071
73 WI-3816 CR-34781 K42 1 CH2 1-2 CR-3071
74 WI-3816 CR-34781 K42 3 CH2 1-1 CR-3071
75 WI-3816 CR-34781
K42
3 CH2
2-1
CR-3071
76 WI-3816 CR-34781 K42 5 CH2 2-2 CR-3071
77 WI-3816 CR-34781 K42 5 CH2 3-1 CR-3071
79 WI-33478 CR-3593 K41 A1 K42 A1 CR-3593
80 WI-33777 CR-3593
K41 A2 K42 A2
CR-3593
81 WI-3816 CR-34781 TB4
1
F46
2
CR-34781
81 WI-3816 CR-34781 TB4 1 F46 2 CR-34781
82 WI-3816 CR-34781 TB9 1 F47 2 CR-34781
82 WI-3816 CR-34781 TB9 1 F47 2 CR-34781
83 WI-3816 CR-34781
TB14 1
F48
2
CR-34781
83 WI-3816 CR-34781 TB14 1 F48 2 CR-34781
84 WI-3816 CR-34781 K43 2 F46 1 CR-34781
86 WI-3816 CR-34781 K43 4 F47 1 CR-34781
88 WI-3816 CR-34781 K43 6 F48
1
CR-34781
90 WI-3816 CR-34781 K43
1
CH1 4-2 CR-3071
91 WI-3816 CR-34781 K43 3 CH1 4-1 CR-3071
92 WI-3816 CR-34781 K43 3 CH2 4-1 CR-3071
93 WI-3816 CR-34781 K43 5 CH2 4-2 CR-3071
94 WI-33777 CR-3593
K44 A2
K43
A2
CR-3593
95 WI-3816 CR-34781 TB2 1 F49 2 CR-34781
95 WI-3816 CR-34781 TB2 1 F49 2 CR-34781
96 WI-3816 CR-34781 TB7 1 F50 2 CR-34781
96 WI-3816 CR-34781
TB7 1
F50
2
CR-34781
97 WI-3816 CR-34781 TB12
1
F51
2
CR-34781
97 WI-3816 CR-34781 TB12 1 F51 2 CR-34781
98 WI-3816 CR-34781 K44 2 F49 1 CR-34781
98 WI-3816 CR-34781 K44 2 F49 1 CR-34781
99 WI-3816 CR-34781 K44 4 F50 1 CR-34781
99 WI-3816 CR-34781
K44 4
F50
1
CR-34781
100 WI-3816 CR-34781 K44 6 F51
1
CR-34781
100 WI-3816 CR-34781 K44 6 F51 1 CR-34781
101 WI-3816 CR-34781 K44 1 CH1 6-2 CR-3071
102 WI-3816 CR-34781 K44 1 CH1 5-2 CR-3071
103 WI-3816 CR-34781
K44
3 CH1 5-1 CR-3071
104 WI-3816 CR-34781 K44 3 CH2 5-1 CR-3071
105 WI-3816 CR-34781 K44 5 CH2 5-2 CR-3071
106 WI-3816 CR-34781 K44 5 CH1 6-1 CR-3071
107 WI-3816 CR-3071 CH1 6-2 CH2 6-2 CR-3071
108 WI-3816 CR-3071 CH1 6-1 CH2 6-1 CR-3071
116 WI-33777 CR-3593 K44 A2 N7 11 CR-33509
117 WI-33777 CR-34783 TB27 18 N7 12 CR-33509
118 WI-33777 CR-33509 N7 31 CB-X10 8 CR-34783
119 WI-33777 CR-33509
N7
32 CB-X10
7
CR-34783
120 WI-3816 CR-34781 TB3 1 F43 2 CR-34781
120 WI-3816 CR-34781 TB3 1 F43 2 CR-34781
121 WI-3816 CR-34781 TB8 1 F44 2 CR-34781
121
WI-3816 CR-34781 TB8
1 F44 2
CR-34781
122
WI-3816 CR-34781 TB13
1
F45
2
CR-34781
122 WI-3816 CR-34781 TB13 1 F45 2 CR-34781
123 WI-3816 CR-34781 K42 2 F43 1 CR-34781
123 WI-3816 CR-34781 K42 2 F43 1 CR-34781
124
WI-3816 CR-34781
K42 4 F44 1
CR-34781
124 WI-3816 CR-34781 K42 4 F44 1 CR-34781
125 WI-3816 CR-34781 K42 6 F45 1 CR-34781
125 WI-3816 CR-34781 K42 6 F45 1 CR-34781
126 WI-33478 CR-3593 K43
A1 K42 A1
CR-3593
127 WI-33777 CR-3593 K42 A2 K43 A2 CR-3593
L1 WI-3817 BARE BK-33996 L1 TB3 2 CR-33043
L1 WI-3817 BARE BK-33996 L1 TB4 2 CR-33043
L1 WI-3817 BARE BK-33996 L1 TB5 2 CR-33043
L2
WI-3817
BARE
BK-33996
L2
TB8
2
CR-33043
L2 WI-3817 BARE BK-33996 L2 TB9 2 CR-33043
L2 WI-3817 BARE BK-33996 L2 TB10 2 CR-33043
L3 WI-3817 BARE BK-33996 L3 TB13 2 CR-33043
L3 WI-3817
BARE
BK-33996 L3
TB14 2
CR-33043
L3 WI-3817 BARE BK-33996 L3 TB15
2
CR-33043
5017438-1W
# WI-STOCK T-CO NN. FROM TERM LOC TO TERM LOC L-CONN.
50 WI-33478 CR-34783 CB-X02 7 K45 A1 CR-3593
85 WI-3816 CR-34781 F46 1 K45 2 CR-34781
87 WI-3816 CR-34781 F47 1 K45 4 CR-34781
89 WI-3816 CR-34781 F48 1 K45 6 CR-34781
110 WI-33777 CR-3593 K44 A2 K45 A2 CR-3593
111 WI-3816 CR-34781 K45 3 CH2 7-2 CR-3071
112 WI-3816 CR-34781 K45 1 CH1 7-1 CR-3071
113 WI-3816 CR-34781 K45 1 CH2 7-1 CR-3071
114 WI-3816 CR-34781 K45 5 CH1 7-2 CR-3071
Convection System: 20-20, 208V, 3PH, Touch
