Wiring Diagram 77529
77529
20.10 440V CONVECTION SIMPLE
AFT
440-480V, 3PH
20-10 (18.9KW (X2))
5016396-1W
# WI-STOCK T-CONN. FROM TERM LOC TO TERM LOC L-CONN.
60 WI-3816 CR-34781 TB1 1 F40 2 CR-34781
60 WI-3816 CR-34781 TB1 1 F40 2 CR-34781
61 WI-3816 CR-34781 TB6
1 F41 2
CR-34781
61 WI-3816 CR-34781 TB6 1 F41 2 CR-34781
62 WI-3816 CR-34781 TB11 1 F42 2 CR-34781
62 WI-3816 CR-34781 TB11 1 F42 2 CR-34781
63 WI-3816 CR-34781
K41 2
F40
1
CR-34781
64 WI-3816 CR-34781 K41 4 F41
1
CR-34781
65 WI-3816 CR-34781 K41 6 F42 1 CR-34781
67 WI-3816 CR-34781 K41 1 CH1 3-2 CR-33008
68 WI-3816 CR-34781 K41 1 CH1 1-2 CR-33008
69 WI-3816 CR-34781
K41
3 CH1
1-1
CR-33008
70 WI-3816 CR-34781 K41 3 CH1 2-1 CR-33008
71 WI-3816 CR-34781 K41 5 CH1 2-2 CR-33008
72 WI-3816 CR-34781 K41 5 CH1 3-1 CR-33008
79 WI-33478 CR-3593
K41 A1
K43
A1
CR-3593
80 WI-33777 CR-3593 K41 A2 K43 A2 CR-3593
90 WI-3816 CR-34781 K43 1 CH2 3-2 CR-33008
91 WI-3816 CR-34781 K43 1 CH2 1-2 CR-33008
92 WI-3816 CR-34781 K43 3 CH2 1-1 CR-33008
93 WI-3816 CR-34781 K43 3 CH2
2-1
CR-33008
94 WI-3816 CR-34781 K43 5 CH2 2-2 CR-33008
95 WI-3816 CR-34781 K43 5 CH2 3-1 CR-33008
116 WI-33777 CR-3593 K43 A2 N7 11 CR-33509
117
WI-33777 CR-33509
TB27
18
N7 12
CR-33509
118 WI-33777 CR-33509 N7 31 CB-X10 8 CR-34783
119 WI-33777 CR-33509 N7 32 CB-X10 7 CR-34783
121 WI-3816 CR-34781 K43 2 F43 2 CR-34781
121 WI-3816 CR-34781 K43 2 F43 2 CR-34781
122
WI-3816 CR-34781 K43
4 F44 2
CR-34781
122 WI-3816 CR-34781 K43 4 F44 2 CR-34781
123 WI-3816 CR-34781 K43 6 F45 2 CR-34781
123 WI-3816 CR-34781 K43 6 F45 2 CR-34781
127
WI-3816 CR-34781 K43
2
F43
1
CR-34781
129 WI-3816 CR-34781 K43 4 F44
1
CR-34781
131 WI-3816 CR-34781 K43 6 F45 1 CR-34781
Convection System: 20-10, 440V, Simple
