5000KIT | 5000KIT AUTOMATION SET62
GENERAL WARNINGS AND SAFETY RULES
1. GENERAL WARNINGS AND SAFETY RULES
Y
This manual contains important information concerning safety. Prior to commencing
installation, study closely all the information provided below. Keep this manual for future
reference.
Follow the precautions provided by any applicable regulatory documents and by those in this
manual. Please, observe safety measures when performing any works. Please, ensure compliance
with the requirements of the standards concerning the construction, installation, and operation
of automated doors (EN 12604, EN 12453), as well as other applicable local rules and regulations.
Mounting, connecting, and nal testing of the equipment, commissioning and maintenance
shall be performed only by qualied and trained personnel. It is prohibited to mount, connect,
set up, and operate the product in violation of the requirements because this can result in
damage, injuries, and losses.
It is prohibited to make any changes to any elements of the product structure and use it for any
purposes except as intended. The manufacturer or supplier shall not be liable for any damage
caused by unauthorised changes in the product or its unintended use. The product is not in-
tended for use in the presence of acid, salt, or explosive media.
When performing any works (installing, repair, maintenance, cleaning, etc.) and establishing
connections inside the drive, disconnect the mains circuit. If the master switch or similar device is
out of sight, attach a safety sign stating: ‘Do not turn on. People are working’ and take measures
preventing accidental restoring of the power supply.
The company reserves the right to introduce changes in this manual and the product design with-
out prior notication, subject to preserving the same functional capabilities and purpose of use.
The content of this manual cannot be used as the basis for legal claims.
2. PRODUCT DESCRIPTION
The kit is designed for automating double-leaf swinging gates. The -5000KIT comprises
two linear-type -5000 electric drives and an external CUSD-1 control unit. For automation
of a single-leaf swinging gate, one drive and one external control unit are used. The drive is
self-locking (when a drive is locked, a gate leaf is impossible to move manually without damaging
the drive or the ttings).
2.1 SCOPE OF DELIVERY
SCOPE OF DELIVERY FOR A CUSD-1 CONTROL UNIT
NO. DESCRIPTION QTY, PCS
1 Control module with an enclosure 1
2 Cable duct PG16 4
3 Fuse F10A (spare) 1
4 Fuse F0.8A (spare) 1
Table 1
