5000KIT | 5000KIT AUTOMATION SET 63
PRODUCT DESCRIPTION
SCOPE OF DELIVERY FOR AN AМ-5000 DRIVE
NO. DESCRIPTION QTY, PCS
1 Drive 1
2 Assembly and operation 1
3 Release key 1
4 Rear tting bracket 1
5 Rear and front tting angle 4
6 Front tting bracket 1
7 Drive mounting screw 1
8 Bolt М8 × 30 4
9 Bolt М8 × 16 1
10 М8 nut with a retaining ring 4
11 М12 nut with a retaining ring 1
12 Washer 8 5
13 Lock release lid with a sealing ring 1
14 Guard bar 2
Y
Fasteners (bolts, plugs, anchors etc.) required for xing a drive to a structure (a wall, a post,
a metal construction) are not included in the kit as their type depends on the mounting
method, material and location.
Upon receipt of the product, please, make sure the kit is complete and there is no visible damage
to its components. In case any components are missing, please, contact the product supplier.
2.2 TECHNICAL SPECIFICATIONS
Y
All indicated technical specications are valid at an ambient temperature of + 20 º С (± 5 º С).
Y
Sizes in gures in the manual are shown in millimetres.
TECHNICAL SPECIFICATIONS FOR A DRIVE
PARAMETER AМ-5000
Maximum pulling force, N 3000
Maximum linear speed, mm / s 16
Electric motor power supply 230V Single Phase
Electric motor power, W 150
Capacitor, F 10
Electric motor thermal protection, ° С 120
Maximum absorbed current, A 2
Maximum use intensity (max.) 25 % (S3)
Maximum time of continuous operation, minutes 10
Maximum speed (S, Figure 1), mm 455
Ingress protection rating IP54
Protection class I
Working temperature range, ° С − 30 … + 65
Weight (not more), kg 11.5
Table 2
Table 3
