attention to oxidisation of the components. Replace all parts and units with an unacceptable
degree of wear. Lubricate units as well as drive and gate components as appropriate.
• Check the attachment fittings of the drive and gate. Tighten them, if needed.
• Check if the gate stops precisely in its final positions. If necessary, reprogram the final positions.
• Clean the external surfaces of the drives, safety devices, and the electric lock (if fitted), using
a soft moist cloth. The use of the following for cleaning is forbidden: water jets, high pressure
cleaners, acids and alkali.
• Perform the testing according to the instructions in section 8.1 ‘Testing’.
With the use intensity of 8 ‘open-close’ cycles per day, the product service life is 8 years.
Y
The installation of the drive and automation devices, their maintenance and operation are out
of direct manufacturer’s control. So, the manufacturer shall not be liable for the safety of the
drive and the drive system during the installation works, operation, and maintenance.
10. TROUBLESHOOTING
FAU LT POSSIBLE CAUSE RECOMMENDATION
Drive is not working
(the control unit indicator is o)
No supply voltage, or a fuse
is blown
Check the supply voltage. Check, and if
necessary, replace the fuse
Drive is not working
(the control unit indicator is on)
A faulty electrical connection.
The drive has been released
Check the connections. Make sure that the
inputs on the device with normally closed
contacts are closed. Engage the drive
The gate moves in wrong
directions
Improper electrical
connections
Check the electrical connections
of the drive
The gate does not stop
in terminal positions
Final positions are either not
set up or incorrect
Set up the nal positions of the gate.
Set up the drive operation time
The drive stops while the gate
is moving (a reversal is possible)
Wrong force setting (strong
gusts of wind). Something
hindering the gate motion.
Set up the drive force. Remove the thing
(obstacle) that hinders the gate motion
A gate leaf stops moving
suddenly
The drive motor thermal
protection activated
Let the drive cool down
The drive does not respond
to the obstacles on the optical
axis of photocells
Incorrect operation of
photocells
Check whether the photocells are
operational, replace them, if needed
Y
In case a failure cannot be eliminated based on the information provided in this manual,
consult the service department. Information about the service department can be obtained
from your supplier (vendor, installation company).
11. STORAGE, TRANSPORTATION AND DISPOSAL
The product shall be stored in its packaging in closed dry spaces. Do not expose to atmospheric
precipitation or direct sunlight. Shelf-life is 3 years from the manufacture date. Transportation
can be performed using all types of covered ground vehicles, tted with measures to prevent
shock and movement inside the vehicle.
Disposal of the product shall comply with the regulatory and legal requirements on
recycling and disposal, valid in the user’s country. The product does not contain
substances, posing danger to life and health of people, and the environment.
Table 12
To Next Page
