 5000KIT | 5000KIT AUTOMATION SET68
4.1 MOUNTING DIMENSIONS
Using the mounting dimensions, it is possible to determine approximate locations for attaching
the rear and front drive ttings.
a) b)
c) d)
C
B
A
W
E
α
X
A
W
B
C
E
α
X
B
A
W
C
E
α
X
C
B
E
α
W
A
X
Figure 4. Mounting diagram for a gate opening inwards
a — with a positive  and a hinge axis along the central plane of a leaf;
b — with a negative  and a hinge axis along the central plane of a leaf;
c — with a positive  and a hinge axis beyond the leaf plane;
d — with a negative  and a hinge axis beyond the leaf plane
ENGLISH
