PREPARATION FOR ASSEMBLY
3. PREPARATION FOR ASSEMBLY
Please, check the condition of all components and materials for their suitability and compliance
with the applicable regulatory documents in force.
Please, make sure that the gate design is robust and suitable for the automation; the gate leaves
are moving easily and smoothly when opened and closed; the motion path of the gate leaves
is horizontal (they remain immobile in any position, if stopped). When closed, the gate leaves
should be level with each other throughout the height, should not yield when opened or closed,
the gap on the hinge pins should be small.
Please, make sure that the dimensions and weight of a gate leaf and the planned usage intensity
are within the acceptable limits (section 2.2 ‘Technical specications’).
Please, make sure that the force required to move a gate leaf manually does not exceed 150 N
(~ 15 kg)—for residential / private properties; 260 N (~ 26 kg)—for industrial / commercial facilities.
Greater force than 150 N or 260 N (as applicable) is allowed only at the start of opening or at the
end of the closing cycles. The above forces do not take into account the wind eect and other
weather conditions.
Please, pay attention to the wind loads aecting the drive operation, depending on the gate
leaf type (dimensions and inll density).
Please, make sure that the surface onto which the drive system is installed is solid and can be used
as a reliable and rigid support. If this is not the case, take measures to reinforce the mounting
locations as appropriate.
Please, make sure that there is enough space to mount the drive system, and the space around
the drive allows for easy and safe manual release. The drive cannot be mounted at a height of
more than 2.5 m.
Please, make sure that the drive is protected from being accidentally hit by a passing vehicle.
Otherwise, install a suitable protective device.
Please, make sure that the drive and its components are at a sucient distance from heat sources
and open re. The violation of this requirement can result in the damage of the product, cause
it to malfunction, catch re, or create other dangerous situations.
Evaluate the possible risk degree (impact, compression, jamming, dragging, and other hazards).
Please, identify what additional devices (accessories) are required to prevent possible risks and
ensure compliance with the safety provisions in force.
Please, make sure that the mounting locations for the drive system components are protected
from impacts. The components must be installed at a safe distance from moving parts.
Control devices should be located within sight of the gate, at a height of not less than 1.5 m.
When a gate leaf is more than 2.5 m wide, installing an electric lock is advisable. The electric lock
should be mounted on the gate leaf that opens rst.
Please, make sure that the mains supply is equipped with protective earthing. Make sure that
the protective earthing is of the proper type, and the metal parts of the drive system are con-
nected to the earthing.
Please, make sure that the section of the mains supply, to which the drive is connected, is
equipped with a short circuit protection device (RCD (residual current device) automatic switch
or its equivalent). The distance between the terminals in the protection tripping unit should be,
at least, 3 mm.
The tools and materials used should be intact and comply with the safety norms, standards,
and instructions in force.
