PRODUCT DESCRIPTION
AM5000=1095
S
127
110
124
AM 5000=1095
S
127
110
124
-
Figure 1. Drive dimensions
Figure 2. Usage restrictions:
m—gate leaf weight (kg), w—gate leaf width (m).
The colour highlights the drive application range.
TECHNICAL SPECIFICATIONS FOR A CUSD-1 CONTROL UNIT
PARAMETER VALUE
Supply voltage 230 V (± 10 %) / 50 Hz
Power consumption (max.), W 4
Maximum power consumption at drives, W 2 × 1000
Remote control D ynamic code / 433.92 MHz
Ingress protection rating IP54
Cross-section of connected conductors 2.5 mm max (28-12AWG)
Working temperature range, ° C − 30 … + 65
Dimensions (max.), mm 210 × 266 × 75
Weight (max.), kg 1.2
Table 4
