5000KIT | 5000KIT AUTOMATION SET 77
CONTROL UNIT
COMPONENT DESIGNATION
FU2 Fuse for the low voltage part (F0.8A)
HL3
Display (see table 9 for display indications)
HL4
X1–X4, X9, X10, X13
Electrical connectors
X5, X6 Process connectors
XN1, XN2
Crossovers to select a drive model
(for -5000 drives, the crossovers are obligatory to install)
XN3
Process crossovers
(must be installed to ensure operation of remote controls)
MODULE LEDS
LED INDICATION DESIGNATION ILLUMINATES DOES NOT ILLUMINATE
PH2 Opening safety device (PH2 input)
Was
not activated
Was
activated
PH1 Closing safety device (PH1 input)
Was
not activated
Was
activated
S STOP safety device (S input)
Was
not activated
Was
activated
OP Open or stop command (OP input) Is given Not given
PED Partial opening command (PED input) Is given Not given
SBS Open-stop-close command (SBS input) Is given Not given
CL Stop or close command (CL input) Is given Not given
HL1
Status of the M1 drive connected to the
X2 connector
Voltage
supplied
Voltage
not supplied
HL2
Status of the M2 drive connected to the
X3 connector
Voltage
supplied
Voltage
not supplied
Y
The state of LEDs, when the gate is in an intermediate position or when a command is not
given, is shown in bold.
DISPLAY UNIT INDICATION
INDICATION MEANING
Gate opening
Gate closing
Gate motion stopped
Partial opening of the leaf with the 1 drive
1 drive nal position switch activated (opened)
2 drive nal position switch activated (opened)
Table 8
Table 9
