Overview and Installation
The AMEVision Display User Interface is a graphical user interface and commu-
nications suite for the WDG-V Analyzer.
Display and Keypad
The AMEVision consists of a 4.2" color, 1/4 VGA display and a 19-key keypad. It
features a web interface, Modbus, trend Data Logging/charting, USB ports for
rmware downloads and parameter/trend data uploads. The host can monitor
up to four sensors simultaneously.
Figure 1-1.
AMEVision Display.
ENTER/MENU
Navigation
Arrows
Color 1/4 VGA
HELP
CANCEL/ESCAPE
Numeric Keypad
Overview and Installation | 1-1
