Analog Output
You can direct process readings to any of the three analog output ports.
The sensor you have selected on the HOME screen is the only sensor
whose functions and process will displayed on this menu. To cong-
ure or view any additional sensor, you must select that sensor on the
HOME screen rst.
Figure 2-9.
Analog Output congure
screen.
Function % O
2
Cell mV
Combustibles
Methane
Mode 0–20 mA
4–20 mA
Namur*
Span Enter reading for 20 mA
(%) for O
2
and methane
(ppm) for combustibles
(mV) for cell millivolt
Zero Enter reading for 0/4 mA
(%) for O
2
and methane
(ppm) for combustibles
(mV) for cell millivolt
Track/Hold during Cal** Track during Cal
Hold during Cal
** Dene the signals to send to the selected analog output port during a calibration. You have
the option to either hold the last process reading or track calibration readings.
