M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
1.2 Utilities
Input Voltage: Universal Power Supply (90 - 260 VAC)
Input Frequency: 50/60 Hz
Power Consumption: 150 VA
Fuse: 5 x 20mm 4A time delay
Power Cord Color Code:
United States Outside United States
Hot (live) Black Brown
Neutral Ground White Blue
(Earth) Green Green/Yellow
Main supply voltage fluctuations are not to exceed ±10% of the nominal supply voltage.
1.3 Specifications
Speed:
Weight:
Carton Volume:
Carton Dimensions:
Temperature Sensing Range:
0.01 - 250 RPM
Gross Weight: 26 lbs.; 11.8 kg.
Net Weight: 22 lbs.; 10.0 kg.
2.48 cu. ft.; 0.07 m3
21 in. (53 cm) W x 12 in. (30 cm) L x 17 in. (43 cm) H
-100˚C to 300˚C (-148˚F to 572˚F)
±1.0% of Full-Scale Range
USB B port for use with an attached PC
USB A port (x3) for use with a USB Flash Drive and Dymo Printer
RJ45 Ethernet port for network connection
Viscosity Accuracy:
Viscosity Repeatability:
Temperature Accuracy:
Operating Environment:
Electrical Certification:
The use of accessory items will have an eect on the measurement
accuracy. See Appendix B
±0.2% of Full-Scale Range
±1˚C | -100˚C to +149˚C
±2˚C | +150˚C to +300˚C
0˚C to 40˚C temperature range (32˚F to 104˚F) 20% - 80% R.H.:
non-condensing atmosphere Conforms to CE Standards:
BSEN 61326-1:2013: Electrical equipment for measurement, control and
laboratory use - EMC requirements.
BSEN 61010-1:2010: Safety requirements for electrical equipment, for
measurement, control, and laboratory use. BSEN IEC 63000:2018:
Technical documentation for the assessment of electrical and electronic
products with respect to the restriction of hazardous substances (ROHS
3).
Ball Bearing Option
If you ordered the ball bearing suspension system with your new instrument, please note the following:
• The ball bearing suspension in your AMETEK Brookfield instrument is noted on the serial tag on the back
of the head by the letter “B” in the part number (the ninth digit; for example: XDVNTHBTBG0U00.
• When attaching and detaching the spindle, it is not necessary to lift the coupling where the spindle
