M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
APPENDIX K - LABORATORY STANDS
Model G is the standard laboratory stand which comes with the DVNext Rheometer.
Figure K-1: Model G Laboratory Stand
Item Part No. Description Qty
1 VS-CRA-14S Upright Rod and Clamp Assembly 1
2 VS-CRA-18S Upright Rod and Clamp Assembly Optional
3 GV-1201 Base, includes 2 GV-1203 leveling screws 1
4 502028071S33B Flat Washer 5/16 X 7/8 X .071 1
5 50S311832S01B Screw, 5/16 - 18 X 1” Hex Head 1
6 GV-1203 Leveling Screws available separately or in
assembly above
2
