M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
Model QB is an optional laboratory stand which can be ordered for use with the DVNext Rheometer. The advantage
is the rapid speed of movement for lowering and raising the rheometer head.
Figure K-2: Model QB Laboratory Stand
Item Part No. Description Qty
1 VSQA-100Y Upright Rod and Clamp Assembly 1
2 GV-1201 Base, includes 2 GV-1203 leveling screws 1
3 502028071S33B Flat Washer 5/16 X 7/8 X .071 1
4 50S311832S01B Screw, 5/16 - 18 X 1” Hex Head 1
5 GV-1203 Leveling Screws available separately or in
assembly above
2
