M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
APPENDIX F - CALIBRATION PROCEDURES
The accuracy of the DVNext is verified using viscosity standard fluids which are available from AMETEK Brookfield or
your local authorized dealer. Viscosity standards are Newtonian, and therefore, have the same viscosity regardless of
spindle speed (or shear rate). Viscosity standards, calibrated at 25°C, are shown in Table F-1 (Silicone Oils) and Table
F-2 (Mineral Oils).
Container Size:
Temperature
Conditions:
For Viscosity Standards < 30,000 cP, use a 600 mL Low Form Grin Beaker having a working
volume of 500 mL.
For Viscosity Standards > 30,000 cP, use the fluid container. Inside Diameter: 3.25” (8.25 cm)
Height: 4.75” (12.1 cm)
Note: Container may be larger but may not be smaller.
As stated on the fluid standard label: (+/-) 0.1°C
The DVNext should be set according to the operating instructions. The water bath must
be stabilized at test temperature. Rheometers with the letters “LV” or “RV” in the model
designation must have the guard leg attached (see Appendix G for more information on the
guard leg).
Normal 25
0
C
Viscosity (cP)
Standard Fluids
Viscosity (cP)
High Temperature Standard Fluids
Three Viscosity/Temperatures**
5 5,000 HT-30,000
10 12,500 HT-60,000
50 30,000 HT-100,000
100 60,000
**25ºC, 93.3ºC, 149ºC, Refer to AMETEK Brookfield catalog for more information
Table - F1
Mineral Oil Viscosity Standard Fluids
BEL Part No. Viscosity (cP) 25
0
C
B29 29
B200 200
B600 600
B1060 1,060
B2000 2,000
B10200 10,200
B21000 21,000
B73000 73,000
B200000 200,000
B360000 360,000
Table - F2
