M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
the status bar.
There is no provision currently to have other drivers for other printers work with the DVNext.
The DVNext Rheometer can configure the printout for several formats of paper/labels. These various paper/label
stocks are available from AMETEK Brookfield. (see Figure 2-21)
Label Type Part Number - Standard Part Number - Long Life (7 yr.)
Data label, small
(1.13 X 3.5 in.)
GV-1048 GV-1082
Data label, large
(2.31 X 4 in.)
GV-1049 GV-1083
Continuous paper
(2.25 in. wide)
GV-1047 GV-1081
Figure 2-21
Printer formats are detailed below:
Data Label (small) Data Label (large)
TIP: When printing to a label, if the data set includes more than one point, only the last point will be printed.
Data Continuous
To Next Page
