M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
Save: Save data.
Configure Test: Return to Configure Viscosity Test screen.
Scroll Bar: Move up/down through a page of data.
The Results screen oers several options for viewing test data. These options are accessed via the Down Arrow in
the Navigation Bar at the top of the screen (see Figure 3-44).
Figure 3-44
Table
Display all data points. Data will be shown in a scroll list where each page can hold a maximum of 50 points. If the
data set has more than 50 points, then additional pages will be indicated at the bottom of the screen. Additional
pages of data can be accessed using the Blue Arrows.
Each data point includes: Viscosity, Torque, Speed, Temperature, Time, Shear Stress (SS), Shear Rate (SR), Density,
and Accuracy.
Post test averaging
Average and Standard Deviation are calculated for measured and calculated parameters including: Viscosity, Torque,
Shear Stress, and Temperature.
Post Test Averaging is calculated regardless of the Data Collection setting. If Data Collection was set to Multi-point
Averaging, then the Post Test Averaging will calculate an average of the averaged data.
When using multiple step programs, the test step utilized for Post Test Averaging is specified in the Report setting
(see Section III.11).
Test used
Display the test elements used to generate the data set. In this view, the Configure Test button is available. Selecting
Configure Test will program the DVNext to run the same test utilized to collect the data set being viewed and present
