Dansensor® LeakPointer 3/3
+
EN User Guide 17
P/N 380064-F
06/2021
Compressed air
(LeakPointer 3 only)
Connect a compressed air supply hose to the “COMPRESSED AIR” inlet.
Make sure
- that the hose between the device and the pressure regulator is max. 1m, otherwise you
must compensate for the pressure drop in the hose.
- that the hose is pushed into the fitting as far as it goes
- to check the connection by pulling the hose slightly outwards
- that the hose and the compressed air complies with the specifications as specified in
"Compressed air supply" on page 88
CAUTION! When connecting the hose, make sure that it can not be squeezed or
blocked in any way.
CAUTION! If the specified maximum pressure is exceeded, there is a danger of
bursting of tubing and other components.
NOTE! If the air supply pressure is below or above the specified input pressure, the
system may not function as intended.
Filter recommendations
It is recommended to install a filter with a degree of filtration down to 5m.
Network Cable
If you plan on using network data logging, you should connect a LAN/Ethernet cable from
the LAN connector (labeled
) to a connector on your local area network.
This cable is not delivered with the device.
NOTE! Use shielded cables for optimal noise immunity.
NOTE! Always consult your network administrator before making network settings,
as incorrect settings can result in reduced or no network activity.
USB Connection
The device has two USB connectors (labeled ), one on the backside and one on the front
below the control panel.
They can be used for connecting a USB Memory stick for exporting/importing log data,
device settings etc. and for connection of a bar-code scanner
and/or a printer .
