Dansensor® LeakPointer 3/3
+
EN User Guide 23
P/N 380064-F
06/2021
Statistics counter The counter shows the number of completed tests ( ) for the
current product as well as the number of leaks found ( ).
The counter is only displayed when the device is in Ready
mode.
The counter counts up to 9999 after which it starts again from
0, and it resets if the device is switched off and on again or if
another product is selected.
However, it is possible to reset the counter for the currently
selected product if the same product is selected again.
Calibration alert Next calibration in 1 - 30 days
Calibration period expired/exceeded
Pressing the icon displays a pop-up window with information
about the calibration alert:
Menu icon Pressing this icon will take you to the Main Menu.
See "Main menu" on page 55 for details.
Date & Time Current date and time.
Status area In the status area the workflow status/progress is displayed.
See "Performing a workflow/measurement" on page 50 for
details.
Print All measurement data can be printed continuously on a
connected USB-printer - see
"Printer" on page 28 for details.
Press the button to edit the required number of print-outs
(0-9).
The button shows the currently selected number of print-outs.
Acknowledge
Measurement buttons
The buttons appear on the measuring screen if
Acknowledge Measurement is enabled in Main Menu
-> Workflow
Press the appropriate button after performing a measurement
to
Validate measurement
Mark measurement as invalid
Mark measurement as invalid and apply additional
comment
The choice determines how the measurement is recorded in
the collected data list - see
"Collected data" on page 72 for
details.
