Controller / User Interface | 4-7
Display
This menu option allows you to define what information should appear
on the top three display lines of your Series 2000 control unit. Choices for
each line are as follows:
O
2
Cell temperature
Cell millivolts
Thermocouple millivolts (T/C millivolts)
Current date/time
User text
Turn off (leave display line blank)
When you access menus, menu options can occupy Display Lines 3
and 4, and sometimes Display Line 2. Therefore, we recommend that
you put the information that is most critical for you to view on the
first and second display lines.
Setting Up the Display
1. Select Display from the Setup menu.
2. Select Display Line #1, Display Line #2, or Display Line #3, de-
pending on where you want to place the information.
3. Select the type of information you want to place on the display line.
Entering user text
User text can be up to 20 characters long.
The Down Arrow Key appearing on the third line of the display allows
you to see which position you’re currently on when entering your user
text message. When you first select the User Text option, this Down Arrow
Key will appear above the first position.
