Controller / User Interface | 4-27
Alarms 1 and 2 are hard wired for the watchdog timer and service
alarms. They are not selectable in software.
Oxygen alarms are disabled during a primary or regular calibration.
In addition, alarms are disabled during start-up until the sensor
reaches its proper operating temperature.
Oxygen alarms are also disabled during a system alarm condition.
See the “Wiring” section in the Installation chapter for help on alarm con-
nections and how alarms are labeled on the control unit wiring card.
Alarm Key
Figure 4-6.
Alarm Key menu.
Alarm Key
Alarm
Set Points
Alarm
Configure
Relay
Configure
Exception
Log
Select
Function
To Next Page
