Ammann APH 50/75 - Ad Ju Sting; lo Cking the Draw Bar

3.4 Ad ju sting / lo cking the draw bar
3.4.1 Ad ju sting the draw bar
•
The op ti mum wor king height can be ad jus ted by mo ving the
stop buf fer (1). Coun ter af ter ad ju sting the buf fer with the wing
nut (2).
3.4.2 Lo cking the draw bar
•
The hand le can be fi xed in up right (3) po si ti on.
•
The draw bar lock ma kes it ea sier to hand le the ma chi ne when
loa ding it.
45020000-2 HbmG gnu thci dreV nna mmA 9102/90
3. Ope ra ti on
55
Be wa re of ma te ri al da ma ge.
If the shaft is locked dur ing nor mal op er a tion, parts of
the lock ing mech a nism can be dam aged.
w
Ne ver lock the shaft du ring nor mal ope ra ti on.
