4.2 Ope ra ti on
The va ri ous ope ra ting sta tu ses are shown on the con trol pa nel
as fol lows:
•
The sys tem starts au to ma ti cal ly when the ma chi ne is start ed.
Next, the sys tem in itia li zes:
• The status LED (8) blinks; the LEDs (0-7) light up in a row
from 0 to 7 and then go back off.
•
Af ter suc cess ful in itia li za ti on, the sta tus LED (8) glows. The
sys tem is now rea dy to operate.
•
The re la ti ve com pres si on va lue is shown by the LEDs as fol -
lows. The num ber of glo wing LEDs sym bo li cal ly re pre sents
the in crea sing soil compression.
LED
VG
0 1 2 3 4 5 6 7
0 – 19 %
l
20 – 40 %
l l
41 – 60 %
l l l
61 – 80 %
l l l l
81 – 100 %
l l l l l
101 – 120 %
l l l l l l
121 – 140 %
l l l l l l l
141 – 150 %
l l l l l l l l
l – red
VG – De gree of com pres si on
•
If the sta tus LED glows, and the 0 LED blinks, the vi brat ion fre -
quen cy is to high or too low. No mea su re ment va lue can be
cal cu la ted.
•
If the 0 LED glows, and the sta tus LED gi ves off a blink sig nal,
the mea su ring sys tem is mal functio ning. In this case, con tact
Am mann service.
45020000-2 HbmG gnu thci dreV nna mmA 9102/90
w
Cor rect mea su re ment va lu es can only be achie ved
by dri ving for ward and bac kwards at ma xi mum
speed.
4. ACE sys tem
