AMX DXLink User Manual

NetLinx Programming of DXLink Transmitters and Receivers
97
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Common DXLink Transmitter / Receiver SEND_COMMANDs
Common NetLinx SEND_COMMANDs for the DXLink Transmitters and Receivers are provided in the
following table. These commands can be sent to any port (#3 Toggle must be set to ON).
Common NetLinx SEND-COMMANDs (Transmitters and Receivers)
Command Description
?FWVERSION
Requests the firmware
version of the
TX or RX.
Syntax:
SEND_COMMAND <DEV>,"'?FWVERSION'"
Example:
SEND_COMMAND dvRX,"'?FWVERSION'"
Returns a COMMAND of the form:
FWVERSION <version-string>
LED-DIS
Disable all LEDs to the
right of the Program
port.
Syntax:
LED-DIS
Example:
SEND_COMMAND DEVICE_1,"'LED-DIS'"
Disables all LEDs to the right of the Program port on DEVICE_1.
Note: This parameter does not get stored in non-volatile memory. LEDs are enabled
by default at each power-up.
LED-EN
Enable all LEDs to the
right of the Program
port (default).
Syntax:
LED-EN
Example:
SEND_COMMAND DEVICE_1,"'LED-EN'"
Enables all LEDs to the right of the Program port on DEVICE_1.
REBOOT
Reboot the module.
Syntax:
REBOOT
Example:
SEND_COMMAND DEVICE_1,"'REBOOT'"
Reboots DEVICE_1.
SET_NDX_DESC
Set Friendly name and
location for NDP.
Syntax:
SET_NDX_DESC-friendly name:location
Max of 25 characters for friendly name and max of 25 characters for location. If more
than 25 characters are sent for either friendly name or location, they will be truncated
to a max of 25 characters.
Neither the friendly name nor the location should contain a “:” character, as that is
used as a delimiter.
Note: This command requires a reboot to enable new settings.

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
