Appendix E – Supported Input Resolutions
131
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Appendix E – Supported Input Resolutions
Available Pixel Display and Refresh Rate
The available pixel display and refresh rates for the input devices connected to the DXLink Transmitters
are listed in this appendix.
The resolutions in the following tables are supported on the DXLink Transmitters and can be set using a
SEND_COMMAND. The horizontal/vertical/refresh information from the Resolution Name
(in the first column) can be entered in a SEND_COMMAND (VIDIN_PREF_EDID) to specify the
preferred resolution for the VGA video input for the Transmitters. For complete command information,
see page 87.
DVI, HDMI and VGA Supported Input Resolutions
DVI, HDMI, and VGA Supported Input Resolutions
Resolution
Name
Horizontal
Active
Pixels
Vertical
Active
Pixels
Refresh
(Hz)
HDMI
and DVI
Support
VGA
Support
Comments Video
Standard
640x400@85 640 400 85   VESA DMT
640x480@60 640 480 60   VESA DMT
640x480@72 640 480 72   VESA DMT
640x480@75 640 480 75   VESA DMT
640x480@85 640 480 85   VESA DMT
720x400@85 720 400 85   VESA DMT
720x480p@60 720 480 60   480p CEA 861
720x480p@120 720 480 120   480p CEA 861
720x480p@240 720 480 240   480p CEA 861
720x576p@50 720 576 50   576p CEA 861
720x576p@100 720 576 100   576p CEA 861
720x576p@200 720 576 200   576p CEA 861
800x500@60 800 500 60   VESA CVT
800x600@56 800 600 56   VESA DMT
800x600@60 800 600 60   VESA DMT
800x600@72 800 600 72   VESA DMT
800x600@75 800 600 75   VESA DMT
800x600@85 800 600 85   VESA DMT
848x480@60 848 480 60   VESA DMT
848x480@75 848 480 75   VESA CVT
848x480@85 848 480 85   VESA CVT
1024x640@60 1024 640 60   VESA CVT
1024x768@60 1024 768 60   VESA DMT
1024x768@70 1024 768 70   VESA DMT
1024x768@75 1024 768 75   VESA DMT
1024x768@85 1024 768 85   VESA DMT
1152x864@75 1152 864 75   VESA DMT

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
