AMX DXLink User Manual

Appendix F – Supported Output Resolutions
135
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Appendix F – Supported Output Resolutions
HDMI and DVI Supported Output Resolutions
The resolutions in the following table are supported on the HDMI RX and can be set using a
SEND_COMMAND. The horizontal/vertical/refresh information from the Resolution Name (in the first
column) can be entered in a SEND_COMMAND command (VIDOUT_RES_REF) to specify scaling
parameters for the HDMI RX. For complete command information, see page 81.
Important: The resolutions and timings in the table below can only be changed with
SEND_COMMANDs.
HDMI and DVI Supported Output Resolutions
Resolution
Name
Horizontal
Active
Pixels
Vertical
Active
Pixels
Refresh
(Hz)
Comments Video Standard
640x480@60 640 480 60 VESA DMT
640x480@72 640 480 72 VESA DMT
640x480@75 640 480 75 VESA DMT
800x600@60 800 600 60 VESA DMT
800x600@72 800 600 72 VESA DMT
800x600@75 800 600 75 VESA DMT
1024x768@60 1024 768 60 VESA DMT
1024x768@70 1024 768 70 VESA DMT
1024x768@75 1024 768 75 VESA DMT
1280x720p@50 1280 720 50 720p CEA 861
1280x720p@60 1280 720 60 720p CEA 861
1280x768@60 1280 768 60
1280x800@60 1280 800 60 VESA CVT
1280x1024@60 1280 1024 60 VESA DMT
1360x768@60 1360 768 60 VESA DMT
1440x900@60 1440 900 60 VESA CVT
1600x1200@60 1600 1200 60 VESA DMT
1680x1050@60 1680 1050 60 VESA CVT
1920x1080@60 1920 1080 60 1080 VESA CVT
1920x1080p@50 1920 1080 50 1080p CEA 861
1920x1080p@60 1920 1080 60 1080p CEA 861
1920x1200@60 1920 1200 60 Reduced
Blanking
VESA CVT-R

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
