Appendix A – Upgrading the Firmware
108
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Important Upgrade Information
Caution: Upgrading the firmware is a serious action in that if the upgrade fails, it can leave the
system completely non-operational.
In the Event of Power Loss During an Upgrade
If power loss occurs before any firmware information has been transferred – when power is restored, the
module will remain operational using the original firmware.
If power loss occurs after some of the firmware information has been transferred but before the transfer
is complete – when power is restored, the module will time out and will not operate until a successful
upgrade takes place.
Caution: If the application signals a failure, you must immediately reboot the Transmitter or
Receiver and attempt to upgrade the firmware again, as the module is in an unknown state and
cannot be guaranteed to be operational.
Firmware Versions
The following table contains firmware version information for the DXLink units.
DXLink Firmware Versions
Applies to Version # Date Differences
HDMI RX 1.0.80
and earlier
10/19/2012 • A/V SEND_COMMANDs respond with STRINGs
• SEND_COMMANDs must be sent in uppercase
HDMI RX 1.0.80
or above
01/07/13 • Supports PS-POE-AT-TC (FG423-84) and
PDXL-2 (FG1090-170)
HDMI RX 1.3.X or
above
03/07/13 • A/V SEND_COMMANDs respond with COMMANDs
• SEND_COMMANDs are not case sensitive
• Updated VIDOUT_ASPECT_RATIO and
VIDOUT_TESTPAT commands.
HDMI TX 1.1.26
and earlier
9/24/2012 • A/V SEND_COMMANDs respond with STRINGs
• SEND_COMMANDs must be sent in uppercase
Multi-Format TX /
Multi-Format Wallplate TX
1.0.44 7/19/2012 • A/V SEND_COMMANDs respond with COMMANDs
• SEND_COMMANDs are not case sensitive
Multi-Format TX /
Multi-Format Wallplate TX
1.0.45 7/19/2012 • Same as 1.0.44
• Modified VGA EDID
• Added: VIDIN_PREF_EDID command for VGA input
HDMI TX /
Multi-Format TX /
Multi-Format Wallplate TX
1.2.X 10/19/2012 • A/V SEND_COMMANDs respond with COMMANDs
• SEND_COMMANDs are not case sensitive
• Added: VIDIN_HDCP command for HDMI input
HDMI TX* 1.2.X 10/19/2012 • When loading any 1.2.X version to an HDMI TX,
you must send the FACTORYAV command to reset
the AV registers (see page 98)
All Transmitters 1.2.40 or
above
01/07/13 • Supports PS-POE-AT-TC (FG423-84) and
PDXL-2 (FG1090-170)
All Transmitters 1.4.7 06/12/13 • Supports 3D, Deep Color, High Bit Rate Audio, and
limited Telnet support of SEND_COMMANDs
(no queries).
• Includes new VGA EDID AMX_0500_003.
• Supports custom VGA EDID using DGX
Configuration Software and Program port.
HDMI RX 1.5.8 06/12/13 • Supports 3D, Deep Color, and limited Telnet support
of SEND_COMMANDs (no queries).
• Includes v1.0.0.6 FPGA code.
• Adds “show vs100 stats” Telnet command.
