Installation and Setup
54
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Multi-Format TX or HDMI TX – Applying Power
Important: If desktop power is used to power the Transmitter, only the provided desktop power
supply should be used and it must not
be altered in any way. Remote power can only be provided via
a switcher or a DXLink power injector. AMX does not support the use of any other power supplies or
power injectors as these may potentially damage the DXLink equipment.
Important Power Considerations for Enova DGX Endpoint Systems
Local power – Local power (desktop power supply) always takes precedence over power via
the DXLink line from the switcher. However, if a locally powered module is connected to a
switcher and the local power is lost (i.e., unplugged or turned off), the module will power
down and then automatically power back up using power from the switcher via the DXLink
connection (increasing the overall power draw on the switcher). When local power is restored,
it automatically replaces the power over the DXLink line.
DXLink power – When modules are being powered by an Enova DGX DXLink board or
DXLink power injector (using power via the DXLink line), to maintain the switcher’s power
redundancy, we recommend that you:
Determine the power budget based on the Input/Output boards used and the quantity of
powered endpoints (modules); see page 38.
Do not use local DC power jack on module (even if local power adapter is turned off).
Note: When using DXLink Power from an Enova DGX Switcher, we recommend wiring a technical
ground for the ungrounded sources/destinations with respect to the DXLink Transmitters/Receivers
and switcher (see page 45).
The following instructions do not apply if you are using power from the switcher via the DXLink line in
an endpoint system.
To apply power to the Multi-Format TX or HDMI TX:
1.
Plug the cord from the desktop power supply (provided) into the power jack on rear of the module
(2.1 mm DC jack for 12 V local power).
2. Plug the desktop power supply into an AC external power source.
The Power LED on the front of the module turns a constant green, which indicates a ready state.
Some of the additional LEDs also turn a constant green. For normal LED display, see table below.
Multi-Format TX and HDMI TX– Indicator LEDs
The LED indicators are listed in the table as they appear on the front of the module from left to right.
Multi-Format TX
and HDMI TX LEDs
Normal Display Indicates
Power Green Power is applied to the Transmitter
Digital Video Green A digital signal is present through the Transmitter
Audio Green A digital audio signal is present through the Transmitter
Analog Video
(Multi-Format TX only)
One of the 3 LEDs
is Green
Type of analog video present through the Multi-Format TX:
• C (composite) or Y/c (2 component)
• Y/PB/PR or RGB (3 component)
• RGBHV (5 component) or RGBS (4 component)
IR TX Red IR TX active communication
IR RX Yellow IR RX active communication
232 (Serial) TX Red Serial TX active communication
232 (Serial) RX Yellow Serial RX active communication
NetLinx Link/Act Green Active LAN connection to an AMX Network
(Blinking = #3 Toggle OFF)
NetLinx Status Green LAN connection is active
CEC OFF CEC is not currently supported
USB Yellow USB is not currently supported. This functionality will be
available in a future firmware upgrade.
