Network Configuration
65
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Factory Default Parameters
Factory Default Parameters
Parameter Value
MAC Address As set in Factory
Serial Number As set in Factory
Ethernet Mode Auto (i.e., speed, duplex, both, auto)
IP Addressing Mode DHCP
IP Address (for static mode) 192.168.1.2
Netmask (for static mode) 255.255.255.0
Gateway (for static mode) 192.168.1.1
DNS1 (for static mode) 192.168.1.1
DNS2 (for static mode) 192.168.1.1
DNS3 (for static mode) 192.168.1.1
DNS Domain amx.com
Hostname Last 7 digits of the serial number
Master Connection Mode NDP - For details, see page 119.
Master URL (for TCP and UDP
URL modes)
“” (blank)
Master Connection Port Number
(for TCP and UDP URL modes)
1319
Friendly-Name “” (blank)
Note: If the Friendly Name is non-blank, both Friendly Name and Location
are concatenated to make NDPSTRING2, otherwise NDPSTRING2 is
generated from the unit’s serial number.
Location “” (blank)
Stored MAC Address of Master
(used for NDP binding)
00:00:00:00:00:00
ICSP Device Number 0 (0 = receive dynamic device number from Master)
System Number 0
Telnet Port 23
A value of 0 disables the Telnet server. Telnet is enabled by default.
SET BAUD 9600, N, 8, 1
CTOF Time 5 (0.5 seconds)
CTON Time 5 (0.5 seconds)
Receivers Only
VIDOUT_ASPECT_RATIO STRETCH
VIDOUT_RES_REF 1280x1024,60 (for Manual Mode)
AUDOUT_FORMAT All
Transmitters Only
VIDIN_AUTO_SELECT ENABLE
VIDIN_FORMAT HDMI (on Port 7), VGA (on Port 8)
VIDIN_RES_AUTO ENABLE
VIDIN_RES_REF 1280x1024,60
VIDIN_PREF_EDID 1920x1080p,60
VIDIN_EDID MIRROR OUT 1 (on Port 7), ALL RESOLUTIONS (on Port 8)
VIDIN_HDCP ENABLE
VIDIN_VSHIFT 0
VIDIN_HSHIFT 0
VIDIN_PHASE 0
AUDIN_FORMAT_AUTO ENABLE
AUDIN_FORMAT Analog
