AMX DXLink User Manual

Product Overview and Specifications
25
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
DXLink Transmitters and Receiver Specifications
The specifications apply to the following Transmitters and Receiver:
FG1010-310 – DXLink Multi-Format Transmitter Module
FG1010-300 – DXLink HDMI Transmitter Module
FG1010-320-BL – DXLink Multi-Format Wallplate Transmitter, Black*
FG1010-320-WH – DXLink Multi-Format Wallplate Transmitter, White*
FG1010-325-BL – DXLink Multi-Format Decor Wallplate Transmitter (US), Black*
FG1010-325-WH – DXLink Multi-Format Decor Wallplate Transmitter (US), White*
FG1010-500 – DXLink HDMI Receiver Module
* A limited set of specifications apply, as the Wallplate TX and Decor Wallplate TX have a limited set of
features when compared to the Multi-Format TX and HDMI TX.
AMX reserves the right to modify its products and their specifications without notice.
General Specifications
Parameter Value
Approvals CE, UL, cUL, FCC Class A, RoHS
AC Power (Modules Only) • 100 to 240 VAC single phase, 50 Hz to 60 HZ
• 0.6 A @ 115 VAC max.
DXLink Power • TX and RX Modules: Power can also be supplied by a DXLink
Power sourcing device such as an Enova DGX 8/16/32 Digital
Media Switcher or compatible Enova DVX All-In-One Presentation
Switcher (e.g., -3155HD) or PS-POE-AT-TC High Power PoE
Injector (FG423-84) or PoE injector PDXL-2 (FG1090-170). AMX
does not support the use of any other power supplies or PoE
injectors as these may potentially damage the DXLink equipment.
• To use PS-POE-AT-TC or PDXL-2 as a power source, the TX and
RX modules require firmware v1.2.40 for TX and v1.0.80 for RX or
above.
• Power Budget: When installed in conjunction with the Enova DGX
Digital Media Switcher, use the Enova DGX Configuration Tool
located at www.amx.com/enova to determine the power
requirements of the configuration and whether any of the DXLink
Transmitters or Receivers should be powered with the local power
supplies or the supported Power over DXLink injectors. The
configuration tool contains instructions on how to determine power
requirements.
• Wallplate TX & Decor Wallplate TX: Power must be supplied by a
DXLink Power sourcing device such as an Enova DGX 8/16/32
Digital Media Switcher or compatible Enova DVX All-In-One
Presentation Switcher (e.g., -3155HD) or PS-POE-AT-TC High
Power PoE Injector (FG423-84) or PoE injector PDXL-2
(FG1090-170). AMX does not support the use of any other power
supplies or PoE injectors as these may potentially damage the
DXLink equipment.
• To use PS-POE-AT-TC or PDXL-2 as a power source, the
wallplates require firmware v1.2.40 or above.
Power Consumption,
Local 12 V Supplied (max.)
Multi-Format TX 10 W (13.5 V), HDMI TX 9 W, HDMI RX 18 W
Power Consumption,
Enova DXLink Power Supplied (max.)
Multi-Format TX 10 W, HDMI TX 9 W, Wallplate TX 7 W,
Decor Wallplate TX 7 W, HDMI RX 15 W
Thermal Dissipation,
Local 12 V Supplied (max.)
Multi-Format TX 34 BTU/hr. (13.5 V), HDMI TX 31 BTU/hr.,
HDMI RX 61 BTU/hr.
