NetLinx Programming of DXLink Transmitters and Receivers
91
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
IR SEND_COMMANDs
On the DXLink Transmitters and Receiver Modules, IR CHANNELS and SEND_COMMANDs are sent
to Port 3 (IR output).
IR CHANNELs
IR SEND_COMMANDs
Channel Function
1-255 Generate the IR or serial command assigned to that channel.
IR SEND_COMMANDs (Transmitters and Receivers)
Command Description
CAROFF
Disable the IR carrier
signal until a 'CARON'
Send Command is
received.
Syntax:
SEND_COMMAND <DEV>,"'CAROFF'"
Example:
SEND_COMMAND IR_1,"'CAROFF'"
Stops transmitting IR carrier signals to the IR port.
CARON
Enable the IR carrier
signals (default).
Syntax:
SEND_COMMAND <DEV>,"'CARON'"
Example:
SEND_COMMAND IR_1,"'CARON'"
Starts transmitting IR carrier signals to the IR port.
CH
Send IR pulses for the
selected channel.
• All channels below 100 are transmitted as two digits.
• If the IR code for ENTER (function #21) is loaded, an Enter will follow the
number.
• If the channel is greater than or equal to (>=) 100, then IR function 127 or 20
(whichever exists) is generated for the one hundred digit.
Note: Set the Pulse and Wait times with 'CTON' and 'CTOF' (see the next page).
Syntax:
SEND_COMMAND <DEV>,"'CH',<channel number>"
Variable:
channel number = 0 to 199 channels
Example:
SEND_COMMAND IR_1,"'CH',18"
The IR port on the DXLink TX or RX performs the following:
• Transmits IR signals for 1 (IR code 11).
• The transmit time is set with the CTON command.
• Waits until the time set with the CTOF command elapses.
• Transmits IR signals for 8 (IR code 18).
• Waits for the time set with the CTOF command to elapse.
If the IR code for Enter (IR code 21) is programmed, the module performs the
following steps:
• Transmits IR signals for Enter (IR code 21).
• Waits for the time set with the CTOF command to elapse.
