Installation and Setup
61
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Detailed NetLinx (Link/Act and Status) LED Behavior
The tables below provide detailed descriptions of all blink patterns for the NetLinx Link/Act and Status
LEDs on the front of the Transmitter and Receiver Modules.
Note: The term “light show” refers to the back-and-forth scanning pattern of the LEDs associated
with the LEDs on the modules.
Module Operational State as Indicated by LEDs
To determine the operational state (normal boot) of a module by its LEDs, check both the Link/Act and
Status LED columns.
ID Pushbutton Boot State and LED Behavior
To monitor the ID Pushbutton boot state of a module by its LEDs, check both the Link/Act and Status
LED columns.
NetLinx LED Behavior and Operational State
Link/Act LED Status LED Module Operational State
ON if connected to a system
with an integrated Master.
Blink OFF with data.
Follow Master’s instruction for Blink
Message if online with Master, otherwise
ON.
Normal Online with Master (rest)
OFF ON Normal Boot (DHCP found)
Note: This state continues from the
time an IP address is obtained until
the device is online with the Master.
Fast blink, then normal
operation.
ON Normal Boot (DHCP, no server)
Note: This state continues until a
valid IP address is obtained.
OFF during light show, then
normal operation (OFF until
connected to Master).
Fast blink (continues only during light
show), then ON until first blink from
Master.
Normal Boot (Static IP)
Note: This state continues until the
device finishes its light show.
ID Pushbutton Boot and NetLinx LED Behavior
ID Pushbutton Boot States Link/Act LED Status LED
Boot with ID Pushbutton held down. Slow blink (1 Hz) Slow blink (1 Hz)
ID Pushbutton held down long enough
for reset to default parameters.
Fast blink until ID Pushbutton is
released, then OFF
Fast blink until ID Pushbutton is
released, then OFF
ID Pushbutton held down long enough
for reset to default firmware image.
Solid ON, transitions to OFF
once the unit completes writing
to flash and is ready to reboot.
Solid ON, transitions to OFF
once the unit completes writing
to flash and is ready to reboot.
In Auto ID mode. Normal Blink (2 Hz)
ID Pushbutton held down long enough to
accept new ID.
2 blinks, then normal 2 blinks, then normal
After boot: ID Pushbutton held down, but
not long enough for IP mode change.
Slow blink (1 Hz) Slow blink (1 Hz)
After boot: ID Pushbutton held down long
enough for IP mode change.
Fast blink, then OFF Fast blink, then OFF
