Network Configuration
63
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Network Configuration
Overview
DXLink Modules support two IP Addressing Modes: Static IP and DHCP (with link-local fallback*).
To avoid having a large system consume numerous IP addresses, the Transmitter and Receiver default to
disabling the network connection functionality. Therefore, the #3 Toggle must be set to ON before the
Transmitter or Receiver can establish a network connection (see page 42).
When #3 Toggle is ON, the DXLink Modules are automatically placed in DHCP Mode, but they can be
configured for either of the IP Addressing Modes via two methods:
The front-panel ID Pushbutton (see page 66)
Telnet commands (see page 111)
* “Link-local fallback” is a method by which an IP host, as a fallback from DHCP, can derive
a local network-unique IP address by negotiating with the other IP hosts on the same network.
Link-local can also be used in its own right as the primary method of IP address allocation. For details,
see “DHCP Mode” below.
Static IP Mode – Default Parameters
Important: Static IP Mode will not function until the #3 Toggle on the DIP switch is set to ON (see
page 42). The #3 Toggle must be ON before the device is accessible via SEND_COMMANDs.
DHCP Mode
Important: DHCP Mode will not function until the #3 Toggle on the DIP switch is set to ON (see
page 42). The #3 Toggle must be ON before the device is accessible via SEND_COMMANDs.
DHCP Mode requires a connection to a network with a DHCP server located on it. This connection can
be either indirect or direct.
Indirect connection – In the case of an Enova DGX Digital Media Switcher or an Enova DVX
Solution (Endpoint Mode) that is connected to a DHCP server device, the DHCP connection
can be propagated through the system’s DXLink layer. First you must complete the following:
Set the #3 Toggle to ON to enable the network connectivity.
Direct connection – In the case of a standalone pair (Extender Mode), to place the DXLink
Modules in DHCP Mode you must complete the following:
Set the #1 Toggle to ON to enable access to the physical ICS LAN 10/100 port.
Set the #3 Toggle to ON to enable network connectivity (DHCP).
Connect the ICS LAN 10/100 port to a network where a DHCP server is located.
Default Parameters For Static IP Mode
Address 192.168.1.2
Netmask 255.255.255.0
Gateway 192.168.1.1
DNS1 192.168.1.1
DNS2 192.168.1.1
DNS3 192.168.1.1
