Appendix C – Virtual NetLinx Master

124

Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver

3. Click Communication Settings on the right.

The Communication Settings dialog box opens.

4. Under Transport Connection Option, select Virtual NetLinx Master.

5. Under Virtual NetLinx Master Options:

a. Optional – Change the Master System Number (default = 1; range = 1 to 65535).

b. Select the desired IP Address in the Available Connections list (this will be the static IP address

that the PC was set to in the previous instructions).

Select Virtual NetLinx Master

Select IP Address (PC’s static IP address)

Change Master System Number (optional)
