AMX DXLink User Manual

Appendix E – Supported Input Resolutions
133
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Composite and S-Video Supported Input Resolutions
Component Video Supported Input Resolutions
Composite and S-Video Supported Input Resolutions
Resolution Name Horizontal
Active Pixels
Vertical
Active
Pixels
Refresh
(Hz)
Comments Video
Standard
720x480i@60 720 240 60 480i CEA
720x576i@50 720 288 50 576i CEA
Component Video Supported Input Resolutions
Resolution Name Horizontal
Active Pixels
Vertical
Active
Pixels
Refresh
(Hz)
Comments Video
Standard
720x480i@60 720 240 59.9 480i CEA 770.2
720x480p@60 720 480 59.9 480p SMPTE 293M
CEA 770.2 ITU-
R BT. 1358
720x576i@50 720 288 50 576i
720x576p@50 720 576 50 576p ITU-R BT. 1358
1280x720p@50 1280 720 50 720p50 SMPTE 296M
1280x720p@60 1280 720 59.9 720p SMPTE 296M
CEA 770.3
1440x960p@60 1440 960 59.9 960p
1920x1080i@50 1920 540 50 1080i50 SMPTE 274M
1920x1080is@50 1920 540 50 1080i_S295M SMPTE 295M
1920x1080i@60 1920 540 59.9 1080i SMPTE 274M
CEA 770.3
1920x1080p@50 1920 1080 50 1080p50 SMPTE 274M
1920x1080ps@50 1920 1080 50 1080p_S295M SMPTE 295M
1920x1080p@60 1920 1080 59.9 1080p SMPTE 274M

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
